Description
Technical Details:
Limit values
Maximum capacity: 8200 g
Readability: 0.1 g
Repeatability (at nominal load): 0.1 g
Linearity deviation: 0.2 g
Sensitivity temperature drift: 3 ppm/°C
Typical values
Repeatability (at nominal load): 0.07 g
Minimum sample weight (acc. to USP): 210 g
Minimum sample weight (U=1 %, k=2): 14 g
Minimum sample weight OIML: 5 g
Settling time: 1 s
Internal adjustment: yes, FACT
Weighing technology: MonoBloc
Interfaces RS232C: 2 ( COM1, COM2)
Balance dimensions (W x D x H): 184x290x84 mm
Weighing pan dimensions: 170×190 mm
Weight of balance: 3.4 kg
Weights for routine testing
Large Weight/Class OIML/ASTM: 5000 g / F2/4
Small Weight/Class OIML/ASTM: 200 g F2/4
