Specifications – JL602-G/L Goldbalance
Trade Name: JL602-G/L/A,JL602-G/L/M
Description
Technical data JL602-G/L
Readability: 0.01 g
Max. load: 610 g
Taring Range: 0 … 610 g
Repeatability (sd): 0.01 g
Linearity: 0.03 g
Sensitivity temperature drift (10 °C … 30 °C): 10 ppm/ °C
Typical stabilization time: 3 s
Adjustment weight external: 500 g (optional)
Level indicator: yes
Number of leveling screws: 2
Weighing pan: ø 120 mm
External dimensions of balance (W/D/H) in mm: 194/225/67
External dimensions of balance with auxiliary display (W/D/H) in mm: 194/286/67
External dimensions of packaging (W/D/H) in mm: 350/275/140 (0.0127 m3)
Net weight (with packaging): 1.0 kg (2.1 kg)
